HVFO-0002-00
| Product No. | HVFO-0002-00 |
| Type | Coupling |
| Center WL(λ㎚) | 1550 |
| AR coating WL(λnm) | 1250~1650 |
| EFL(㎜) | 0.996 |
| L1(㎜) | 0.95 |
| L2(㎜) | 4.35 |
| OI(㎜) | 6.9 |
| M | 4.2 |
| NA | 0.57/0.135 |
| Dimension(㎜) | Ø3.0XT1.6 |
Specification
| Item | Unit | Value |
| Part Number | HVFO-0002-00 | |
| Type | Coupling Lenses | |
| Center Wave Length | λ nm | 1550 |
| AR Coating Wave Length | λ nm | 1250~1650 |
| Effective Focal Length | mm | 0.996 |
| Beam Diameter | mm | |
| Working Distance (L1) | mm | 0.950 |
| Numercial Aperture (Object) | 0.570 | |
| Size (W×H×CT) | mm | Ø3.0*1.6 |
| Material | Optical Glass(RoHS compliant) |
